Acoustical Movable Doors Operable Wall Partitions for Hotel Banquet Hall
Movable Partition Walls Details
Acoustical movable partition walls material is designed to address the most basic needs of schools, churches, hotel, coffee room, inspection hall, exhibition center, station, art hall, auction center, stadium, KTV partitions, art museum, testing center, convention center, airport, conference center, library, training facilities and office environments.
With the unique multi-layer panel system, our pattern 100 sound proof partition wall has excellent acoustic performance with a STC up to 50dB.
Double PVC seals are mounted around the acoustical movable partition walls to provide the highest level of acoustic integrity. More importantly, this fit can also achieve the desired acoustic integrity between two nearby rooms.
The acoustic structure includes multi-layer board at the top and bottom of the acoustic movable partition walls and the glass wool inside. The acoustic performance is up to 40 STC, and the fabric wrapped acoustic panel and perforated MDF panel can be used to reduce echo. The vinyl at all edges help to prolong life time and seal the noise.
These banquet hall acoustical movable partition walls will be provided in an end-folded configuration to meet a variety of parking requirements and the first panel can be provided as a standard access door.
Specifications of Acoustic Movable Partition Walls System
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Pass doors | Single door or Double door |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
Advantages of Acoustical Movable Partition Walls
Economic overhead support with angle iron
Easy setup and collect
No auxiliary storage tracks or support are required.
The panels are designed to be stored at both ends or one end of the opening.
Smooth operation banquet hall acoustical movable partition walls
Simple automatic bottom seal for efficient operation
Suitable for applications that require superior durability, soundproof and frequent use.
Ideal for classrooms, meeting rooms or soundproof office movable partition walls.
Acoustical movable partition wall is designed to address the most basic needs of schools, churches, hotel, coffee room, inspection hall, exhibition center, station, art hall, auction center, stadium, KTV partitions, art museum, testing center, convention center, airport, conference center, library, training facilities and office environments.
