85 mm Thickness Melamine Accepted ODM OEM Hanging Sliding Removable Partition Wall
Product Description
1. Overhead type track, you just need to install the orbit on the floor or on the rack, there is no track on the floor, have no damage on the ground.
2. Unique aluminum materials ,which can be used for painting.
3. It is convenient to collect, plate can be hide in special coffer, have no effect to the whole appearance.
4. It is widely used for many occasions.
We offer
1.No floor track and soundproof partition wall
2.OEM and ODM services accepted
3.Free sample provided
4.Quiet shipping within 15 days
5.Get product warranty for 3 years and accessories warranty for 10 years
| Technical Parameter for Partition Panel | Panel Width | 500~1230mm |
| Panel height | 2000~4000mm |
| Sound proof | 32~38db |
| Operation | Manual |
| Frame | Aluminum |
| Vertical profile | Anodised aluminum profiles with integrated magnetic strip and sealing edges on the inside |
| Finish options | Fabric, veneer, HPL melamine, vinyl, carpet, customers own material, Bare finish |
| Base options | Plywood, Gypsum, steel, MDF |
| Max width | Unlimited |
| Panel weight | 25-40kg/sq |
| Pass door selection | door | Single or double door |
| Seals | Top | Manual |
| bottom | Manual |
Advantage
Our easy lock-up set: Retractable pressure seals on top and bottom are extended and retracted by a single 180°turn removable operating handle.
Retractable Pressure Seals: Once the panel is positioned, they are sealed in place with retractable pressure seals.
Telescopic sleeve panel: Final closure of the wall is achieved by extending a telescopic sleeve on the last panel. The sweep strip simultaneously extends the top and bottom. The rubber sealing strip on the side edge of telescopic panel can seal the wall tightly to reach acoustic integrity.
About the price of the movable partition wall
Our movable partition wall is customized, the cost is calculated by area, the thickness of different partition wall and the price of various finishes are different. Therefore, we need you to provide detailed dimensions such as height width and finish requirements to get a quote. If possible, we also need your layout.
About procurement procedure
Firstly , send us the shop drawings(if the shop drawings is not available , you can tell us the height from false ceiling
to finished floor and width from wall to wall)
Secondly , we offer you the movable wall layout drawings for your confirmation
Thirdly , we quote the movable wall in accordance with confirmed drawings .
about finish options
BUNGE provides panel finishes such as MDF, melamine, fabric, leather, wood veneer, acoustic panels or other custom surfaces.
