Interior Aluminum Sliding Folding Acoustic Partitions Wall For Meeting Room
| Series | BG 65 | BG 85 | BG100 |
| Panel supension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 400 mm | 600 mm | 800 mm |
| Panel width | 600-1230 mm | 600-1230 mm | 600-1230 mm |
| Face material | 9 mm | 9 mm | 9 mm |
| Pass doors | Single Door or Double Door |
| Sound insulation | 20 – 32 db | 28 – 36 db | 32 – 50 db |
| Finish Material | Plywood / MDF /Laminate / Melamine / Gypsum |
| Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized) |
Partitions wall description
Type 65
Product information: partition thickness is 65 ㎜, single wheel and single piece of double wheel, can open U and L door in the door, every piece of maximum load of 225 ㎏, screen or 22.5 ㎜ scale range.
Product property: magnetic strip is vertically embedded, sealed and soundproof.
Among them: the datum is fiber board or plywood, its sound insulation factor RW = 32 db, density of 24 ㎏ / ㎡.
Application: the partition height is 2.5m ~ 4m.Between 5 meters.
Type 85
Product information: partition thickness is 85 ㎜, single wheel and single piece of double wheel, can open U and L door in the door, every piece of screen maximum load of 450 kg, bottom top 22.5 ㎜ scale range.
Property: magnetic strip is installed at the connection of two screens, which will attract itself when close to each other. It has good sealing and sound insulation performance.
Among them: the datum is fiber board or plywood, its sound insulation factor RW = 40 db, density of 28 ㎏ / ㎡, .
Application: the partition height is between 3 meters and 7.5 meters.
Type 100
Product information: partition thickness is 100 ㎜, monolithic single wheel and single piece of type, can open U and L door in the door, every piece of screen of maximum load of 675 ㎏, or 30 ㎜ scale range.
Property: magnetic strip is installed at the connection of two screens, which will attract itself when close to each other. It has good sealing and sound insulation performance.
Among them: the datum is fiber board or plywood, its sound insulation factor RW = 50 db, density of 32 ㎏ / ㎡.
Application: suitable for partition height between 5 m ~9 m.
Features and applications
This partition has the characteristics of high sound insulation, fire prevention, movable, simple operation, etc.
At present, activity partition, fixed partition, mobile partition series products have been widely used in hotels, guesthouses, multi-functional halls, conference rooms, banquet halls, office buildings, exhibition halls, financial institutions, government offices, hospitals, factories and other occasions.
We are manufacture supplier of movable partitions wall,acoustic panel and office furniture.we have our own factory and showroom in Guangzhou.Welcome to visit us.
