Decorative Movable Partition Wall For Exhibition Show Room Sound Proof partition room divider partition
1.Specifications:
· Aluminum or steel top hung system.
· Retractable top and bottom seals ensure the effortless movement of panels and sound-proof.
· Concealed or exposed panel edge profiles.
· Sealed for life roller assemblies provides smooth and silent movement.
· Several levels of sound reduction.
· Extensive range of surface finishes available.
2.Technical information
| Series | BG65 | BG80 / BG85 | BG100 & BG125 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodized with sealing profiles | Aluminum anodized with sealing profiles | Aluminum anodized with sealing profiles |
| Retractable seals | Aluminum black with
double rubber seals | Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied
operating handle | Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or
double open in two panel | Single open in a panel or double open in two panel | Single open in a panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wallpaper, Vinyl, Painting, etc.(Customized) |
3.Acoustic room dividers features
1. The acoustic room dividers varied, and the characteristics of the hotel can be selected according to the overall decoration style of the hotel.
2. The outer frame of acoustic room dividers is made of aluminum alloy, and its decorative surface is satisfied according to the customer's needs. For example, the veneer is made of non-combustible material and has strong fireproofing material. And the sound insulation effect of the partition is also very good.
3. The acoustic room divider is highly utilized, its design is the integration of parts, which is to facilitate the better combination, so its combination is powerful, it can be reused, which reduces the cost of customers, can also achieve environmental protection. Energy-saving and other functions.
