Hanging System Acoustic Partition Walls for Exhibition Center / Banquet Hall

Name: Hanging System Acoustic Partition Walls for Exhibition Center Banquet Hall
Brand: BUNGE
Price: 72 USD

China Hanging System Acoustic Partition Walls for Exhibition Center / Banquet Hall factory

Brand Name : BUNGE

Model Number : Series 65 mm exhibition partition walls

Certification : ISO9001

Place of Origin : Guangdong

MOQ : 10 squaremeters

Price : 72/ 118dollars per square meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000 squaremeters per month

Delivery Time : Shipped in 10 days after payment, based on the quantity

Packaging Details : Carton package, MDF batten on four section sides , foam board on both front face.

Panel width : 500 mm--1220 mm (Accept Customized)

Material : MDF+Aluminum

Application : Hotel,Office ,Conference room,Banquet hall

Color : Color Selective (Customized)

Weight : 600/1230mm

Thickness : 65 mm(2 9/16 inch)

Finish : Melanimine,Fabric,Leather

Feature : Voice Insulation

Contact Now

Hanging System Sound Proofing Acoustic Partition Walls for Exhibition Center

Specification:

1) Track system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers.

2) Surface panel shall be of 9mm or 12mm MDF with acoustic treatment to the required level.

3) Consists of required full wall elements and telescopic elements with 2-point suspension system with steel-roller, extruded aluminium track.

Hanging System Acoustic Partition Walls for Exhibition Center / Banquet Hall

Bunge Operable Wall Systems-Technical Information

Series	BG65	BG80 / BG85	BG100 & BG125
Panel suspension	Top hung only	Top hung only	Top hung only
Track system	Single or twin point	Single or twin point	Single or twin point
Panel thickness	65mm	80mm / 85mm	100mm
Panel height	Up to 4000mm	Up to 6000mm	Up to 18000mm
Max height	4000mm	6000mm	18000mm
Panel width	600-1230mm	600-1230mm	600-1230mm
Frame construction	Aluminum frame	Aluminum frame	Aluminum frame
Face material	9mm	9mm / 12mm	12mm
Fire safety	Optional Class I or O	Optional Class I or O	Optional Class I or O
Vertical profiles	Aluminum anodised with sealing profiles	Aluminum anodised with sealing profiles	Aluminum anodised with sealing profiles
Retractable seals	Aluminum black with double rubber seals	Aluminum black with double rubber seals	Aluminum black with double rubber seals
Operation of seals	Manual, with supplied operating handle	Manual, with supplied operating handle	Manual, with supplied operating handle
Locking	Optional lock to pass doors	Optional lock to pass doors	Optional lock to pass doors
Pass doors	Single open in panel or double open in two panel	Single open in panel or double open in two panel	Single open in panel or double open in two panel
Sound insulation	20-32dB Rw	28-36dB Rw	32-50dB Rw
Weight	Approx 22-35kg/sq M	Approx 25-40kg/sq M	Approx30-48kg/sq M
Finish Material	Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Hanging System Acoustic Partition Walls for Exhibition Center / Banquet Hall

Advantages :

1) Resistant to water , moisture and mold, antibiosis and easy to clean

2) many sizes: board with thickness from 2mm to 25mm can be made
3) Resistant to abrasion, scratches, and impact
4) Resistant to fire, heat, and cigarette burns
5) various surface processing and colors
6) environmentally friendly

Hanging System Acoustic Partition Walls for Exhibition Center / Banquet Hall

We Offer:

A full professional design service

Survey and installation guide

Using top quality materials and components

A fully experienced work team

Maintenance contracts to ensure your valuable asset remains in full work order.

Hanging System Acoustic Partition Walls for Exhibition Center / Banquet Hall
